Quick Overview
The Dayton Audio ME652C Micro-Edge speaker provides both left and right channels into a single speaker.
Product Highlights
- • Contemporary, almost-invisible Micro-Edge™ grill design
- • Provides two channels of high-quality audio from a single speaker
- • Dual 1” coaxial silk dome tweeters and dual-coil 6-1/2″ woven Kevlar® cone woofer
- • 12dB/octave crossover with exclusive tuning by Dayton Audio
Product Description
When installing multi-room audio in a confined space such as a kitchen, bathroom, or hallway, you might be tempted to use a single conventional in-ceiling speaker, connected to one amplifier channel. But you’d be missing half the music. Dayton Audio’s ME652C Micro-Edge™ series dual channel ceiling speaker makes it possible to preserve both channels of an audio source, for the complete musical experience with rich tone and excellent sonic detail even in these tight spaces.
Product Details
| Model Number | ME652C |
| Unit of Measure | Each |
| UPC | 848791001321 |
| Warranty – Parts | 5 Years |
| Warranty – Labor | 5 Years |
| Product Shipping Weight (lbs.) | 4.9 |
| Product Height | 9-3/4″ dia. |
| Product Width | — |
| Product Length | — |
| Product Depth | 4″ |
| Speaker Series | Micro-Edge Series |
| Speaker Application | Ceiling |
| Speaker Configuration | 376 |
| Input Rating | 346 |
| Power Handling (RMS) | 35 watts |
| Power Handling (max) | 70 watts |
| 70V Tap Settings | — |
| Frequency Response | 50 – 20 000 Hz |
| Sensitivity | 88 dB @ 1W/1m |
| Woofer Type | Kevlar Cone |
| Woofer Diameter | 6-1/2″ |
| Tweeter Type | Silk Dome |
| Tweeter Size | 1″ |
| Crossover | — |
| Special Features | — |
| Grill Type | Removable Steel Mesh |
| Replaceable Grill | — |
| Magnet Material | — |
| Magnet Weight | — |
| Mounting Hole Size | 8-1/4″ dia. |
| Installation | — |
| Box Includes | — |
Product Manuals / Spec Sheets / Downloads
ME652C User Manual
Architectural & Engineering Specification Sheet
