The NFS style is designed to fit in the smallest of depths. This speakers narrow design allows it to be utilized in areas of mounting depths of as little as 1.93″ (50mm). A 6.5″ Polypropylene Trueform™ Woofer and 0.5″ (13mm) Soft Dome Tweeter provide high-quality sound from tight spaces. Although short on depth this style is deep in performance and quality.
| Key Features: | • Smooth Modern Flangeless Design • One Piece Frame to Maximize Rigidity • PRX™ Poly Resin CrossPoint Molds for Increased Rigidity • PRX™ Poly Resin Dog Legs • Extra Wide Threaded Screws for Quick Dog Leg Fastening • Gold Plated Spring Loaded Push Terminals • Dual Coated (Zinc and Powder) Steel Grill firmly attached with Neodymium Magnets • Removable Scrim Cloth • LIFETIME WARRANTY |
|---|---|
| Mechanical Specifications: | • Baffle Diameter: 9.09″ (231mm) • Mounting Depth: 1.93″ (50mm) • Cut Out Dimensions: 8″ (205mm) • Pre-Construction: Use Vanguard PCBC-6 |
| Acoustic Specifications: | • 6.5″ (165.1) Polypropylene Trueform™ Woofer • 0.5″ (12.7mm) Soft Dome Tweeter • 5/50 WPC Power handling • 88db SPL • Impedance 8Ω • Frequency Response 72Hz – 20kHz • Shallow 1.93″ (50mm) Mounting Depth • LIFETIME WARRANTY |
