Quick Overview
What the world really needs are ceiling speakers that sound spectacular, but have a look thats understated – almost invisible. Dayton Audio Micro-Edge coaxial ceiling speakers like the ME820C fill that need like no others on the market.
Product Highlights
- • Perfect for high-end whole house audio applications
- • Contemporary Micro-Edge™ design
- • Kevlar® cone woofers with butyl rubber surround
- • Coaxially mounted 1″ silk dome tweeter
- • 12 dB/octave optimized crossover
299
Fill your home with rich, audiophile-quality sound from Dayton Audios Micro-Edge Series coaxial ceiling speakers, while offering a modern, stealth look for todays contemporary décor.
Tough woven Kevlar cone woofers were selected for their inherent transient response quickness and ability to convey a warm response in the critical midrange, while delivering a bass punch that is missing from most ceiling speakers.
1″ silk dome tweeters provide pristine clarity for the top end of the frequency response spectrum. Additionally, ME620C ceiling speakers may be used as rear and/or side channel speakers in surround sound applications.
All Dayton Audio Micro-Edge Series speakers are timbre matched to provide the best possible home theater experience.
Product Details
| Model Number | ME820C |
| Color | White |
| Unit of Measure | Pair |
| UPC | 848791000140 |
| Warranty – Parts | 5 Years |
| Warranty – Labor | 5 Years |
| Product Shipping Weight (lbs.) | 13.3 |
| Product Height | — |
| Product Width | 11″ diameter |
| Product Length | — |
| Product Depth | 3-7/8″ |
| Speaker Series | Micro-Edge Series |
| Speaker Application | Ceiling |
| Speaker Configuration | 376 |
| Input Rating | 346 |
| Power Handling (RMS) | 45 watts |
| Power Handling (max) | 90 watts |
| 70V Tap Settings | — |
| Frequency Response | 30 – 20 000 Hz |
| Sensitivity | 89 dB @ 1W/1m (±3 dB) |
| Woofer Type | Kevlar |
| Woofer Diameter | 8″ |
| Tweeter Type | Silk |
| Tweeter Size | 1″ |
| Crossover | Yes |
| Special Features | — |
| Grill Type | Metal |
| Replaceable Grill | — |
| Magnet Material | — |
| Magnet Weight | — |
| Mounting Hole Size | 10″ diameter |
| Installation | — |
| Box Includes | — |
Product Manuals / Spec Sheets / Downloads
