Dayton Audios versatile APA150 can deliver 75 watts into 2 channels, or 150 watts into 8 ohms when set to bridge-mono mode. A built-in, switchable low-pass filter makes this a great subwoofer amp, and full range line-level outputs allow for bi-amp configurations.
Product Highlights
- • Virtually noise-free fan operation for near field applications
- • Sleek modern design looks good in any audio system
- • High current, discrete output transistors that run cool and quiet
- • Adjustable 50-150 Hz low pass crossover gives you the room control you need
- • Gold-plated 5-way binding posts that accept up to 8 AWG wire
Amplifiers today need to be multi-faceted to keep up with the task at hand. Versatility is the foundation upon which the APA150 is based. Configured in stereo mode, amplification is provided to a pair of speakers for stereo or surround playback. Select bridge-mono mode and the APA150 is configured for powering a center channel speaker, or a subwoofer/tactile transducer when used with the on-board low pass filter. Full-range line-level outputs allow for daisy chaining amplifiers for a multi-room whole house audio system or for bi-amp applications. A smaller chassis consumes less space than conventional amplifiers making placement options virtually endless.
Key features of the APA150 are high current, discrete power transistors (used in premium amp designs), a hefty toroidal power supply transformer, low-noise forced air cooling, a fully adjustable—and defeatable—electronic 50-150 Hz low-pass filter (18 dB/octave), and complete protection against electrical shorting and thermal overload. Also included is auto-on/off, silent turn-off with no audible transient, gold plated RCA inputs/outputs, and 5-way binding posts.
Product Details
| Model Number | APA150 |
| Color | Black |
| Unit of Measure | Each |
| UPC | 844632061523 |
| Warranty – Parts | 5 Years |
| Warranty – Labor | 5 Years |
| Product Shipping Weight (lbs.) | 13 |
| Product Height | 5.6″ |
| Product Width | 5.7″ |
| Product Length | — |
| Product Depth | 12.8″ |
| Amplifier Type | Power Amplifiers |
| Power Output | 75 watts RMS x 2 into 4 ohms 150 watts RMS x 1 into 8 ohms |
| Power Output (RMS @ 70V) Range | — |
| Output Channels | 2 |
| Output Connectors | 279 |
| Output Types | 285286 |
| Inputs | 1 |
| Input Connectors | 299 |
| Input Impedance | 47 k ohms ±5% |
| Signal-to-Noise Ratio | >100 dB unweighted |
| THD @ Rated Power | Less than 0.01% |
| Parametric EQ | — |
| Phase Adjustment | — |
| Low-pass Crossover | Variable 50-150 Hz 18 dB/octave |
| Low Pass Adjustment | — |
| Dynamic Range | — |
| Frequency Response | 20 Hz – 20 000 Hz |
| Efficiency | — |
| Gain | — |
| Bass Boost | — |
| Voltage Requirement | 120V 60 Hz 230V 50 Hz (switchable) |
| Auto-on Sensitivity | 3 mV |
| Stand-by Power Rating | — |
| Special Features | — |
