An 8″ coaxial ceiling speaker with cone woofer, fluid-cooled soft-dome swivel tweeter, 140W power handling, horn-shaped acoustic baffle and thin, light grille with magnets
- • Blue PP mica cone woofer
- • Fluid-cooled soft-dome swivel tweeter
- • 140W high power handling capacity
- • Horn-shaped acoustic baffle with spiral pattern produces a clean and natural sound
- • Thin grille with slim edge becomes almost invisible after installation
- • Protective plastic cover on the back
- • Light grill with magnetic catch is easy to attach and remove for spray painting and cleaning
- • Large dog-eared clamp with non-slip tread for sure installation
| NS-IC800 | ||
|---|---|---|
| Type | 2-way coaxial | |
| Woofer | 8” (20 cm) PP (polypropylene) mica cone | |
| Tweeter | 1” (2.5 cm) fluid-cooled soft dome, swivel | |
| Frequency Response | 50 Hz – 28 kHz | |
| Maximum Input Power | 140 W | |
| Sensitivity | 90 dB | |
| Crossover Frequencies | 12dB/oct. (3.5 kHz) | |
| Impedance | 8 ohms | |
| Dimensions (W x H x D) | Φ11-1/8” x 4-3/4”; Φ283 x 120 mm | |
| Mounting Depth | 4-1/4” (109 mm) | |
| Weight | 4.2 lbs. (1.9 kg) | |
| I/O connectors | Push Terminal ( Applicable Cable *Max, Twisted wire : 8mm²/ AWG 8) | |
